The Howo 4x4 off road cargo truck is a powerful medium- and short-distance freight transporter designed for complex road conditions. Equipped with a 116-horsepower Yunnei engine and a 6-speed transmission, it delivers powerful and reliable performance. Its upper cargo box has a volume of 5.7 m³ and can carry approximately 5 tons. Its durable construction and retractable side and rear panels significantly improve loading and unloading efficiency, making it suitable for transporting heavy goods such as building materials, agricultural and sideline products, and construction materials.

*HOWO 4x4 Off Road Cargo Truck

HOWO 4X4 Drop Side Cargo Truck*

Our factory is professional manufacturer in truck area,
guarantee all products Brand-New and High-Quality.

» Ⅰ.Product Defination and Introduction:

Manufacturer: CS TRUCKS GROUP LIMITED

Key Features

1. All-rounder, Fearless of Terrain: Built with an all-wheel drive chassis, it boasts powerful all-terrain capabilities.

2. Heavy-duty, Efficient and Reliable: With a legal load capacity of approximately 5 tons, the cargo box features a 4mm thickened floor and 3mm thickened side panels, making it durable and wear-resistant.

3. Flexible Loading and Unloading, Efficiency First: The cargo box features a "three-sided opening" design, supporting forklifts and manual operation from multiple angles, greatly improving the convenience and efficiency of loading and unloading.

4. Dimensionally Compliant, Excellent Passageability: With a total weight of 9,890 kg and a wheelbase of 3,800 mm, the compact body meets heavy-duty requirements while navigating urban and rural roads.

» Ⅱ. Product Parameters for HOWO 5tons cargo truck:

» Ⅲ. Product Details

Chassis Configuration

1. All-Wheel Drive Chassis

• Based on the chassis of the HOWO 2080 single-row light truck with an all-wheel drive cab, this model features a part-time four-wheel drive system, supporting two-wheel drive/four-wheel drive mode switching, making it easy to navigate complex road conditions such as mud, gravel, and snow.



• Front double wishbone independent suspension + rear leaf spring non-independent suspension balance load capacity with comfort on bumpy roads, improving stability by 20% when loaded.

2. Powertrain Matching

• Engine: Yunnei YN4102QBZL 116-horsepower diesel engine, 3.76L displacement, maximum torque of 290 Nm (1800-2100 rpm), with outstanding low-speed high torque and fast climbing power response under full load.



• Transmission: WLY6TS55C 6-speed manual transmission, with a first gear ratio of 6.32, providing ample torque for heavy-load starting; the highest gear (0.79) overdrive ensures economical high-speed cruising.

Upper Design: Large Volume + Flexible Loading and Unloading

1. Cargo Box Parameters

• Dimensions: 4850 × 2150 × 550 mm (L × W × H), with a volume of approximately 5.7 cubic meters. The side and rear panels are constructed of 3mm high-strength steel, and the bottom is reinforced to 4mm, improving impact resistance by 30%.



2. Loading and Unloading Convenience

• Side-Opening and Tailgate Design: The dual side panels and tailgate can be opened and lowered, greatly enhancing loading and unloading convenience.



• Low Cargo Platform Design: The cargo box is only 1.1 meters above the ground, reducing manual handling effort and making it suitable for frequent loading and unloading of grain, oil, and daily necessities.
