HOWO brand Dump trucks, Special large machines for transporting goods, loading and unloading multi-ton materials. The HOWO dump truck is perfect for transporting goods and loading and unloading operations of any complexity. Our company offers a shift rental of special equipment of Kenya and foreign production for any need.Building upon the strengths of the HW79 cabin, this model offers high ground clearance, superior maneuverability, and adaptability to diverse and challenging work environments. The smaller frontal area of the cabin contributes to increased fuel economy and greater cost-effectiveness. The HWT6 cabin is undoubtedly the optimal choice for medium and short-distance transportation.
Working capacity :
40TonsCabin type :
NX flat roof cabin, with sleeperDrive system :
6x4Wheelbase ( mm) :
3200 + 1350Engine specific :
371HP / SINOTRUK WP10.371Gear box :
HW19710, manual 10F and 2RFront axle ( Kg ) :
7000Rear axle ( Kg ) :
18000(2 Axles)The HOWO trucks dump lorry is designed for construction work in the most difficult conditions. The dump truck guarantees long-term trouble-free operation and high productivity. For towing the truck without preliminary unloading, a 35 ton hitch is used. The air suspension and high chassis allow for loads of up to 26 tonnes.
The engine of HOWO trucks dump lorry complies with the Euro2 standard - it has 336-420 horsepower. In this model, the cooling system pump, the crankcase ventilation system were improved and the crankshaft size increased. Truck options include a manual sunroof, a fold-down front step and a lockable radiator grille.
*HOWO 76 series 6x4 heavy duty dump Truck
HOWO 10 wheeler Rear Tipper Truck*
-----------------------------------------------------------------------------
Our factory is professional manufacturer in truck area,
guarantee all products Brand-New and High-Quality.
»Ⅰ. Product Defination and Introduction:
Manufacturer: CS TRUCKS GROUP LIMITED
Features
1, One of the biggest and best truck and trailer manufacturer in China
2, 30 years of experience in Special Vehicle
3, Build a strict QC team to guarantee the quality
4, Fast delivery time
5, 12-24 months long guarantee time assurance
» Ⅱ. Product Parameter for HOWO 6x4 Heavy dump truck:
| Type | HOWO 6X4 DUMP TRUCK | |||||
| Cabin | HW70(No bed), HW76(Single bed). | |||||
| ENGINE | Model | WD615.62 | WD615.87 | WD615.69 | WD615.47 | D10.38-50 |
| Fuel | Diesel | |||||
| ENGINE | Displacement | 9.726L | ||||
| Emission Standard | EURII | EURV | ||||
| Power | 196(266)/2200 | 213(290)/2200 | 247(336)/2200 | 273(371)/2200 | 276(375)/2000 | |
| Torque | 1100/1100-1600 | 1160/1100-1600 | 1350/1100-1600 | 1500/1100-1600 | 1560(1200-1500) | |
| Transmission | Model | HW15710; HW19710; HW19710; THW19712; HW20716 | ||||
| Control Mode | MT | |||||
| Front Axle | HF9 drum-type rated load of 9tons | |||||
| Rear Axles | HC16 16Tbns speed ratio 5.73;4 8;4.42; AC16 I6tons speed ratio1 5 45:4 77; | |||||
| Clutch | Single- plate dry diaphragm spnng clutch, diameter 430(B) mm, hydraulically operating with air assistance | |||||
| Steering | ZF8118. steering gear. ZF steering gear, ZF steering oil pump, system pressure 21Mpa | |||||
| Suspension | Leaf spnng suspension; air spnng suspension | |||||
| Fuel tank | 300L | |||||
| Tyres | Rims: 8.5-20,10 hole-steel Tyres; 12.00-20 Tube; Option: 11 00-20 tube 12.00R20 Tube, 12R22.5 tubeless. 315/80R22 5 tubless | |||||
» Ⅲ. Product Details
Cab
The cabin's body is constructed with a one-piece steel frame, providing robust strength, rigidity, and superior resistance to impacts and external forces. Its safety performance has been proven through stringent crash testing.
The three-level air intake grille makes the classic front mask more layered. Non-slip boarding pedals and 90° opening doors facilitate drivers getting on and off the vehicle.
Air Suspension Seat
The air suspension seat allows drivers to quickly find the optimal sitting position. The integrated design of the seat belt and the seat is ergonomically compliant, avoiding the driver's feeling of suffocation caused by emergency braking during driving.
Four-Point Air Suspension
The four-point air suspension provides excellent stability, shock absorption, and comfort, and features a cabin rearward displacement function during collisions, ensuring passenger safety.
Products--100% Customized Level One!
Transportation--100% Safety, Convenience, Efficient!
Services--7days + 24hours Safetify Service!
We CS TRUCKS also supply spare parts (original, OEM, and replacement) for all types of trucks and trailers
with discount and nice quality to ensure our customers's trucks and trailers being in good working conditions.
» Ⅳ. Applicable Scenarios
The HOWO 6x4 lift truck, with its large capacity, high efficiency, and strong adaptability, is widely used in:
• Short-distance transportation from municipal solid waste transfer stations to treatment plants;
• Scheduled and fixed-point garbage collection in commercial and residential areas;
• Temporary garbage removal for large-scale events.
The Howo 30 ton construction dump truck is modified on the basis of HOWO 6x4 RHD chassis, with a wheelbase of 4325+1350mm, equipped with WP10.380E22 diesel engine, HW19710 speed gearbox, and a dump box made of carbon steel with six sides and eight bottoms, 5400x2300x1200mm, Front lifting, stable lifting, clean and quick unloading, rear doors can be opened, and the vehicle is controlled by the control valve on the driver's side, which is easy to operate.
Read More
HOWO 8×4 dump truck is a robust construction vehicle designed for heavy-duty engineering and mining transportation. Equipped with a Weichai 380 horsepower engine, a sturdy 10mm carbon steel floor cargo box, and an 8×4 drive configuration, it demonstrates exceptional load-bearing capacity and off-road performance. Its front-mounted hydraulic lifting system ensures efficient and reliable unloading operations, making it an indispensable workhorse in global infrastructure projects. Particularly in the African market, it is highly regarded for its durability, reliability, and adaptability.
Read More
